Resolution |
Scan |
600dpi×600dpi |
Print |
1800dpi×600dpi |
Gradation |
256 |
Original type |
Sheets, books, objects (max. weight 2kg) |
Output size |
A3-A5, B6, A6, banner paper |
Image loss |
Top edge: 4.2mm; bottom edge: 3.0mm; right/left edges: 3.0mm |
Warm-up time (23℃, std. voltage) |
Approx. 20 sec. |
First copy out time |
B&W |
6.8 sec. |
Color |
8.4 sec. |
Output speed (A4) |
B&W |
26 ppm |
Color |
26 ppm |
Copy magnification |
Fixed same magnification |
1:1 + / -0.5%or less |
Scaling up |
1:1.154/1.224/1.414/2.000 |
Scaling down |
1:0.866/0.816/0.707/0.500 |
Preset |
3 types |
Magnification |
25-400% in 0.1% steps |
Lengthwise crosswise individual Settings |
25-400% in 0.1% steps |
Standard paper capacity |
Paper tray1/2: 500 sheets; paper tray: 100 sheets |
Paper weight |
Paper tray1~4 |
52-256g/㎡ |
Bypass tray |
52-300g/㎡ |
Multiple copy |
1 to 9,999 sheets |
Auto duplex |
A3-A5, B6, A6 (60~256g/m²) |
Power requirement |
AC220-240V, 8.0A, 50/60Hz |
Power consumption |
1.58 kW or less |
Dimension (W*D*H) |
571x660x881.4mm (with ADF) |
Weight |
Approx. 71kg (with ADF) |
